Bug 52598 - Writer ignores original picture pixel density in .jpg files, and uses 120 dpi (refer comment 19)
Summary: Writer ignores original picture pixel density in .jpg files, and uses 120 dpi...
Status: NEW
Alias: None
Product: LibreOffice
Classification: Unclassified
Component: Writer (show other bugs)
Version:
(earliest affected)
3.6.0.2 rc
Hardware: All All
: medium normal
Assignee: Not Assigned
URL:
Whiteboard:
Keywords:
: 103273 115287 (view as bug list)
Depends on:
Blocks: Writer-Images Image-DPI
  Show dependency treegraph

Reported: 2012-07-27 19:21 UTC by Zoltán Hegedüs
Modified: 2019-03-20 18:51 UTC (History)
4 users (show)

See Also:
Crash report or crash signature:


Attachments
The example .jpg picture with 600 dpi (404.95 KB, image/jpeg)
2012-07-28 12:50 UTC, Zoltán Hegedüs
Details
My own default template for Writer (14.20 KB, application/vnd.oasis.opendocument.text-template)
2012-07-28 12:51 UTC, Zoltán Hegedüs
Details
made on my 1600x900 monitor, with the screen resolution set as 800x600 (416.74 KB, application/vnd.oasis.opendocument.text)
2013-06-20 16:16 UTC, flamingdescent
Details
made on my computer with the 1366x768 screen (416.75 KB, application/vnd.oasis.opendocument.text)
2013-06-20 16:17 UTC, flamingdescent
Details
on my computer with the 1600x900 monitor, with the screen resolution set to its normal resolution (416.75 KB, application/vnd.oasis.opendocument.text)
2013-06-20 16:18 UTC, flamingdescent
Details
Writer used 120 pixel/inch, but this picture has 600 pixel/inch, the display has 144 pixel/inch (417.09 KB, application/vnd.oasis.opendocument.text)
2013-11-17 10:02 UTC, Zoltán Hegedüs
Details
example image (421.94 KB, image/jpeg)
2015-06-21 12:33 UTC, Dirk Munk
Details
Photoshop resize window - resampling off (13.85 KB, image/png)
2015-06-21 12:38 UTC, Dirk Munk
Details
Photshop resize windows - resampling on (14.87 KB, image/png)
2015-06-21 12:41 UTC, Dirk Munk
Details
JPG header information with low-res dpi setting (47.46 KB, image/png)
2017-11-12 18:37 UTC, Dirk Munk
Details
JPG header information with high-res dpi setting (47.40 KB, image/png)
2017-11-12 18:38 UTC, Dirk Munk
Details

Note You need to log in before you can comment on or make changes to this bug.
Description Zoltán Hegedüs 2012-07-27 19:21:46 UTC
I must set the enlargement at all pictures one by one, moreover in 2 places, in turn I set the keep ratio.
Comment 1 Jean-Baptiste Faure 2012-07-28 06:35:59 UTC
Please provide a step by step scenario to reproduce your problem.
http://wiki.documentfoundation.org/BugReport

Best regards. JBF
Comment 2 Zoltán Hegedüs 2012-07-28 12:50:00 UTC
Created attachment 64820 [details]
The example .jpg picture with 600 dpi
Comment 3 Zoltán Hegedüs 2012-07-28 12:51:11 UTC
Created attachment 64821 [details]
My own default template for Writer
Comment 4 Zoltán Hegedüs 2012-07-28 12:58:01 UTC
See the 2 attachments. The bug happens in all cases:

Start Writer, if already running, open a new document (Ctrl+N).
Menu Insert/Insertion: Picture: from file. Or: with drag and drop with the mouse, from the Windows Explorer (File Manager) to the document, or maybe with opening the picture with the Writer, I did not try it. But I tried: munu Insert/Insertion: File.

Windows XP Home SP3 Hungarian.
Because of Writer uses the display resolution, if I open the saved file in an another computer, the picture size can vary. For example, the most common display resolution is 96 dpi.
Comment 5 flamingdescent 2013-06-20 16:16:49 UTC
Created attachment 81120 [details]
made on my 1600x900 monitor, with the screen resolution set as 800x600
Comment 6 flamingdescent 2013-06-20 16:17:32 UTC
Created attachment 81121 [details]
made on my computer with the 1366x768 screen
Comment 7 flamingdescent 2013-06-20 16:18:38 UTC
Created attachment 81122 [details]
on my computer with the 1600x900 monitor, with the screen resolution set to its normal resolution
Comment 8 flamingdescent 2013-06-20 16:32:21 UTC
Computer 1: operating system: Windows 7, LibO version: 4.0.3.3 release (1600x900 screen)
Computer 2: operating system: Windows 8, LibO version: 4.0.3.3 release (1366x768 screen)

Here are the steps I took to create the attached documents:
0. I downloaded your default template and the example .jpg picture.
1. In Windows Explorer, I double-clicked your default template.
2. menu Insert > Picture > From file, selected the picture
3. I saved the file.

My attachments' titles show within parentheses the screen resolution in which the document was made. (e.g.: "Picture Bug (1366x768)" was made on my 1366x768 computer). For the "Picture Bug (800x600)", I changed the screen resolution of my 1600x900 monitor.

I can't reproduce the bug, but that might be because I don't understand what you mean by "picture size". So what do you mean by picture size?
A. the size according to the LibreOffice onscreen ruler? In the combinations [800x600 screen and 800x600* document, 1600x900 screen and all three documents**, 1366x768 screen and all three documents**], the onscreen ruler shows the picture as slightly less than 4 inches high.
B. document size? All the documents are ~416 KB, though their sizes are different by a few bytes.
C. how many pixels are in the picture? For all the documents I attached, I performed these steps:
  1. I right-clicked the picture, selected "Edit with External Tool"
  2. Windows Live Photo Gallery opens. File > Open with > Paint
  3. The Paint status bar says "3200 × 1688 px"

* "800x600 document" refers to the document named "Picture Bug (800x600)
** the three documents I attached

I'm not sure whether this bug involves data loss, so I'll keep the Importance the same.

Because I need a clarification about what you mean by "the picture size can vary", I'm changing the status of this bug to NEEDINFO. When you make the clarification, change the status back to UNCONFIRMED. Thanks for reporting this bug!
Comment 9 Zoltán Hegedüs 2013-06-22 10:33:04 UTC
(In reply to comment #8)

Size of a picture: not in pixels, but for example in millimeters at printing and at the display: not the resolution, but the density: pixel/length. For example, I inserted a 600 dpi picture, but Writer regarded this 120 dpi, because of my monitor setting is 120 dpi. The resolution remained, but the size in millimeters/inches/etc expanded to 5 times.

Example for data loss: if you create this document on an another computer, on where the display resolution is 96 dpi, the picture will be larger, but you maked the same steps. I do not know if Writer stores the resolution of the pictures. If do not, close this document, and open at an another computer with different display settings: the size of the picture varies. The same document looks different on 2 computers. The resolution always remains, but the enlargement varies (the resolution density, pixel/length). For examle, a picture is 2 line height on one computer, and 3 line height on another one.
Comment 10 Zoltán Hegedüs 2013-11-16 15:09:47 UTC
Why is this unconfirmed still?
Comment 11 Jean-Baptiste Faure 2013-11-16 15:49:13 UTC
(In reply to comment #10)
> Why is this unconfirmed still?

Because probably nobody understood what is the problem.
For example, if I look at the three files provided by flamingdescent, I see the same thing. But probably he changed only the size of the screen, not its resolution.

Could you attach two "identical" documents, one made on a computer with 120 dpi screen resolution and one made on a computer with 96 screen resolution?

Best regards. JBF
Comment 12 Zoltán Hegedüs 2013-11-16 19:14:36 UTC
(In reply to comment #11)

Pixel density (in unit pixel/inch) is stored in the .jpg file. Writer ignores this, and uses the display settings. If you insert the same file with 2 computers with different display pixel density, you will get different result in the .odt file. Reproduction: insert a .jpg file to a document, view the size in the document in inches or millimeters, save, exit from LibreOffice. View the actual display density in Windows (Control Panel, Resolution special settings). Modify it. 963 dpi is the default, for example, use 120 dpi or 144 dpi. Restart Windows. Insert the same .jpg file to a new document. The size of the picture in inches or in millimeters will be different.

Another example: the pixel density of a .jpg file is 600 pixel/inch. Insert this to a document, and view the size in the document: if the setting is original size, Writer uses 96 or 120 or 144 dpi: the picture is 5 times bigger.
Comment 13 Jean-Baptiste Faure 2013-11-16 21:07:37 UTC
Please, don't set to new a bug report you created yourself.
I understand your explanations. I just need to see an example.
And what about PNG files?

Best regards. JBF
Comment 14 Zoltán Hegedüs 2013-11-17 08:14:41 UTC
(In reply to comment #13)
> I just need to see an example.
See the attachment https://bugs.freedesktop.org/attachment.cgi?id=64820
> And what about PNG files?
I do not have any png files, so I did not test it.
Comment 15 Jean-Baptiste Faure 2013-11-17 08:42:11 UTC
(In reply to comment #14)
> (In reply to comment #13)
> > I just need to see an example.
> See the attachment https://bugs.freedesktop.org/attachment.cgi?id=64820

No, an example of 2 documents like asked in comment https://bugs.freedesktop.org/show_bug.cgi?id=52598#c11

> > And what about PNG files?
> I do not have any png files, so I did not test it.

It's unfortunate because PNG is the preferred image format for LibreOffice.

Best regards. JBF
Comment 16 Zoltán Hegedüs 2013-11-17 10:02:00 UTC
Created attachment 89344 [details]
Writer used 120 pixel/inch, but this picture has 600 pixel/inch, the display has 144 pixel/inch

I inserted the .jpg file in the previous attachment to an empty document. The pixel density of the .jpg file is 600 pixel/inch, but Writer used 120 pixel/inch. The display pixel density setting is 144 pixel/inch at me. (Writer inserted the picture in 28% size, this is not a bug, because the picture is reduced to the width of the line.)
Comment 17 Zoltán Hegedüs 2013-11-17 10:41:23 UTC
Sorry, there was 120 dpi the display resolution when I observed this error. Writer uses always 120 dpi at inserting .jpg files, and ignores the pixel density stored in the .jpg file (600 dpi in the attachment, so Writer uses 5 times enlargement at this file). The display density is no object, I tried this with 144 and 96 pixel/inch setting. The error is not happen at inserting .png files, I tried to insert 96 and 600 dpi files (at 96 pixel/inch display setting). But the attachment converted to .png with GIMP is 5-times bigger (9 times with Paint instead of GIMP), so it is better to use .jpg files.
Comment 18 Jean-Baptiste Faure 2013-11-21 21:55:58 UTC
Not sure if it is a bug. LibreOffice and before OOo did that since the beginning.
From the point of view of text processor, you should prefer to define the size of the image in the page, not in pixels but in cm.
Not sure too if the pixel/inch is a portable measure from paper to screen or another support. Indeed each support has its own pixel size.

Set status back to unconfirmed.

Best regards. JBF
Comment 19 Owen Genat (retired) 2014-08-01 08:45:15 UTC
(In reply to comment #9)
> ... I inserted a 600 dpi picture, but Writer regarded this 120 dpi,
> because of my monitor setting is 120 dpi. The resolution remained, but the
> size in millimeters/inches/etc expanded to 5 times.

From attachment 64820 [details]:

$ identify -verbose Vegyeskép.jpg | head -n7
Image: Vegyeskép.jpg
  Format: JPEG (Joint Photographic Experts Group JFIF format)
  Class: DirectClass
  Geometry: 3200x1688+0+0
  Resolution: 600x600
  Print size: 5.33333x2.81333
  Units: PixelsPerInch

When I insert this image into a Writer document with a suitably large page size the resultant image is 26.67" wide. 3200 divided by 26.67 = ~120, which is the indicated DPI reported in this bug rather than the 600 DPI stored in the JPEG. If the DPI stored in the JPEG were being respected the image would be inserted at the indicated 5.33333x2.81333 inches.

The only part of the quoted statement I am concerned about is this:

> because of my monitor setting is 120 dpi

The laptop I tested this on appears to have a 100ppi LCD screen (13 9/16 inches wide @ 1366 pixels), so I am not certain the DPI is being derived from the screen. It may be set in the JPEG import filter. Anyway, confirmed under GNU/Linux x86_64 using v4.2.5.2. Status set to NEW. Platform set to All/All.
Comment 20 Owen Genat (retired) 2014-08-01 08:49:15 UTC
It may be that this is not a bug that can be fixed, but we should at least get a developer to look at this. Summary amended to point to comment 19, which contains steps to reproduce.
Comment 21 Dirk Munk 2015-06-21 12:33:21 UTC
Created attachment 116705 [details]
example image
Comment 22 Dirk Munk 2015-06-21 12:35:06 UTC
I ran into the same problem. I prepared some pictures with Photoshop Elements, and wanted to insert them "as is" in a Writer document, but I wasn't able to do so.

When you edit an image in Photoshop, the properties of the image will show the number of pixels (obviously) and the desired DPI setting. The two combined can be used to calculated the desired size of the image in cm or inches.

Writer ignores the desired DPI setting and will always resample the image based on the DPI setting of the screen (96 DPI in my case) and the size of the image in the document.

With Compress Graphic you can change the DPI setting of the image, but that seems to be not of the orginal image but of the the already resampled image.

To makes this clear, the following example. I have an image of 1600 x 1065 pixels. When I insert this image on a A4 page, it will be resampled to fit the width of the page using a resolution of 96 DPI. The resulting image has a size of 642 x 427 pixels.

When I open Compress Graphic I can change the DPI setting back to the original 300 DPI, but then I will get an image size of 2007 x 1335 pixels, so a resampling of the already resampled image will take place. That is not good for the quality of the image, any resampling should be done based on the original image.

In Photoshop Elements there is a setting that allows you to switch resampling on or off. If you switch it off changing the DPI setting is the only way to change the size of the image in cm or inches. With resampling on you can choose any DPI and size in cm or inch.

So in my opinion three things should happen:
1. Writer should use the desired DPI setting of the image if the DPI setting is in the properties of the image (and if possible).
2. If Writer needs to resample an image, it should always use the original image.
3. It should be possible to switch resampling off, and just use the DPI setting to get the desired size in cm or inches.

Attached are an example image, and two screen dumps of the Photoshop window, one with resampling enabled, and one without.
Comment 23 Dirk Munk 2015-06-21 12:38:54 UTC
Created attachment 116706 [details]
Photoshop resize window - resampling off
Comment 24 Dirk Munk 2015-06-21 12:41:06 UTC
Created attachment 116707 [details]
Photshop resize windows - resampling on
Comment 25 QA Administrators 2016-09-20 10:11:48 UTC Comment hidden (obsolete)
Comment 26 Dirk Munk 2017-10-13 13:03:14 UTC
The problem is really very simple. JPEG file headers contain information about the size of the picture, measured in pixels. They also contain information about the dpi setting. The dpi setting is used to calculate the desired picture size in cm or inch, it doesn't do anything else. A high dpi setting will result in a small high resolution picture, a low dpi setting in a large low resolution picture. The dpi setting has nothing to do with the actual contents of the picture, so changing the dpi setting doesn't do anything with this contents. It is very important to keep this in mind.

The problem is that LibreOffice doesn't understand the JPEG headers of at least Photoshop elements. It will not read the dpi setting, instead Libreoffice will use the dpi setting of the display. So a JPEG photo that is intended to be 10cm x 10cm with 300 dpi, will become 31.25cm x 31.25cm in Writer, because I have a 96dpi display. (300/96 x 10 = 31.25)

Libreoffice does understand the JPEG headers of (for instance) Microsoft Paint. If I open a JPEG picture made by Photoshop Elements in Paint, and immediately save it again, that picture will be opened correctly by Libreoffice. However, Paint uses a lower quality compression setting, so the actual contents is changed. Mind you, not the size in pixels, or the dpi setting!!

It is indeed a serious problem, because it prevents people from making high quality documents, high quality meaning high resolution images for printing etc. It can't be very difficult to solve I guess, it just needs someone who knows about these headers, and can find a fool-proof way to handle them
Comment 27 Dirk Munk 2017-11-10 13:47:26 UTC
It is a problem with handling the EXIF headers. The EXIF headers contain information about dpi etc., and LibreOffice doesn't handle them properly. It is a really serious problem if you want to create high quality documents with high resolution pictures. So I'm going to raise the importance to major.
Comment 28 Buovjaga 2017-11-12 17:05:37 UTC
*** Bug 103273 has been marked as a duplicate of this bug. ***
Comment 29 Dirk Munk 2017-11-12 18:36:26 UTC
In a previous comment I stated that the information is in the EXIF headers, this is a mistake, the information is in the standard JPEG headers.

I've uploaded two IrFanView information headers. The difference between the two is the dpi setting in the header, nothing else. That information is used to calculate the print size in cm / inch. It seems that Writer isn't (always) capable to read the dpi setting from the header, and it then replaces the dpi setting by the dpi of the screen. This results in a completely wrong size of the picture in the Writer document. Adjusting the size in Writer results in resampling the picture, and using the wrong, mostly lower, dpi setting.

It's very simple, anyone who is able to understand the way jpg and other graphic files are handled in Writer, can understand this,

Please fix this problem!!
Comment 30 Dirk Munk 2017-11-12 18:37:54 UTC
Created attachment 137701 [details]
JPG header information with low-res dpi setting
Comment 31 Dirk Munk 2017-11-12 18:38:50 UTC
Created attachment 137702 [details]
JPG header information with high-res dpi setting
Comment 32 Buovjaga 2018-03-01 14:50:09 UTC
*** Bug 115287 has been marked as a duplicate of this bug. ***
Comment 33 QA Administrators 2019-03-02 03:51:34 UTC Comment hidden (obsolete)
Comment 34 Dirk Munk 2019-03-20 18:51:42 UTC
The problem still exists, the headers of certain images are still not handled properly. Very annoying.
